onsemi CMOS 이미지 센서 솔루션

onsemi CMOS 이미지 센서 솔루션은 다양한 응용 분야에 맞게 고안된 CMOS 기술을 적용한 이미지 센서입니다. 이 센서는 고속 및 고감도 성능을 발휘합니다. CMOS 이미지 센서에는 메인스트림 CMOS 이미지 센서, 피톤 CMOS 이미지 센서 및 다목적 CMOS 이미지 센서와 같은 세 가지 종류의 센서가 포함되어 있습니다. 일반적으로 머신 비전, ITS(지능형 교통 시스템) 및 스마트 조명에 사용됩니다.

Hyperlux LP: Feature Rich, Ultra-Low Power

Features

• Stacked 1.4µm BSI pixel
• Industry leading low power (e.g. AR0830 – 4k, 30fps, <100mW)
• Stacked design for the smallest size
• Wake-on-motion reduces power
• SmartROI saves bandwidth

Applications

• Doorbell cameras
• Indoor/outdoor home security
• Body cameras
• Battery-powered devices
• Robotics/AMR
• Video conferencing

Series

• AR0544 – 5MP, 1/4” format
• AR0830 – 8MP, 1/3” format
• AR2020 – 20MP, 1/2” format

Hyperlux LH: Superior Low-Light, eHDR

Features

• Stacked 2.0µm BSI pixel
• Up to 120dB dynamic range
• eHDR saves system resources
• High NIR QE for active lighting
• Excellent low-light performance

Applications

• Professional security
• Video conferencing
• Car DVRs
• Factory automation
• Robotics

Series

• AR0246 – 2MP, 1/4” format
• AR0822 – 8MP, 1/2” format

Hyperlux SG: World Class Global Shutter

Features

• 2.8µm GS pixel
• World-class shutter efficiency
• Programmable ROI
• Superior MTF
• Compact size

Applications

• Scanning
• Biometrics
• AR/VR
• Factory automation

Series

• AR0145 – 1MP, 1/4” format
• AR0235 – 2MP, 1/3” format
• ARX383CS – VGA, 1/8” format

Hyperlux

Features:
• 1920 x 1536 at up to 60fps
• On-chip combined HDR RAW output, up to 26-bit (>150dB) with effectively lossless companding down to 24-, 16-, or 12-bit
• Real-time functional safety mechanisms
• ASIL-C design process and ASIL-B hardware metrics
• AEC-Q100 Grade 2
• 4-lane MIPI CSI-2

Series:

• AR0341AT - 1/3.6" optical format

Hyperlux ID

Features:

• 1280(H) x 960(V) resolution
• 1/3" optical format
• 3.5µm BSI pixel
• Global shutter type
• 1.2MP, 60fps frame rate
• 43% QE @940nm
• 200MHz maximum modulation frequency
• >95%modulation contrast
• Up to 60fps @ full res 100fps @ VGA on chip depth FPS

Applications:

• Industrial/commercial:
• Machine vision, factory automation, metrology, and logistics
• Robotics, AGV, SLAM, and drones
• Access/area control and biometrics
• Consumer:
• Gaming, metaverse, and AR/VR (3D capture)
• Gesture recognition (control)
• Vacuum cleaner and humanoid robot

Series:

• AF013X - 1MP 1/3 CIS SO
• AF0131 - 1MP 1/3 CIS SO
